Energy-tight Windows for comfortable living and fuel efficiency



For nearly 40 years, TrimLine has provided quality custom windows for use in replacement, remodeling, new construction and historically certified rehabilitation projects. TrimLine offers a wide variety of products including double hung, casement, bow, bay, awning, picture windows, and sash replacement kits, as well as round top, elliptical and other architectural window products.

Custom colors in either all wood or aluminum clad exteriors and interior hardwoods of oak, cherry, and mahogany are available. Custom extruded panning systems and other trim accessories plus, a variety of simulated divided light as well as authentic true divided lite profiles, and replication of mullion details are some of our custom capabilities.

Clad Wood Replacement
Double Hung Windows



Legends DR200 shown in optional oak interior with simulated divided lite and polished brass hardware.

All Trimline windows are made of the finest quality solid western pine ready for paint or stain and are also available in select hardwoods of oak, cherry and mahogany. All hardwoods used in the window are of actual solid stock not thin veneers or laminates.

Energy-Tight Windows for comfortable living and fuel efficiency

Choice of Jamb Style

The TrimLine DR200 is constructed with a 3 ¼" jamb for a retrofit installation into the sash pocket of existing wood window frames. Virtually identical to a vinyl window installation, the DR200 is truly a replacement window.

The TrimLine DR300 is made with a 4 9/16" jamb for replacement applications requiring complete tear-outs down to a frame or masonary opening. With a snap-in nailing fin, the DR300 is ready for new construction.

Both the DR200 and DR300 can be furnished with factory applied extension jambs making it the ideal choice of window for either replacement/remodeling or new construction.

 TrimLine offers quality wood window products, which are comparable in design, appearance, construction and performance to the major national wood window manufacturers, while priced as a competitive alternative.


Enjoy the beauty and warmth of wood

• The insulating qualities of wood provides a positive thermal break and can be painted or stained.
• All wood parts are produced from the finest quality kiln dried select Western Pine and are treated with a water repellent preservative. Also available in Oak, Cherry, and Mahogany
• Maintenance free aluminum clad exterior is weather resistant. Does not require painting. Available in White, Bronze, Earthtone and Beige. Custom colors are also available.
• Decorative wood bead glazing provides a positive energy tight seal for the insulating glass.
• Fully weather-stripped to insure maximum comfort and low air infiltration.
• Thermally broken sill - TrimLine combines aluminum, wood and vinyl to provide an aesthetically pleasing energy efficient sill construction.
• Matching picture window - TrimLine provides a line of picture windows that matches the profiles of the DR200 and DR300 and enables you to mull window combinations with matching sight lines.
• Choice of screens - standard half or optional full screens.
• Locks are available in bright brass, white or bronze. Two dual action cam locks are used on windows over 28" wide.

Since 1964, Trimline Windows has produced quality custom aluminum clad wood windows for replacement, remodeling and new construction.

All TrimLine windows are custom made on the 1/8" in width and height. Standard and custom jamb depths combined with custom size make TrimLine windows suitable for replacement, remodeling and new construction.



Trimline Casement and Awning Windows

Add Beauty and Elegance through window design



• Corrosion Resistant Hardware - TrimLine uses Truth Entry Guard corrosion resistant, lifetime warranted hardware on all operating casements and awnings. Coastal hardware for use in salt environments is also available.
• 7/8" Insulated Glass - Standard insulated glass is 7/8" overall using double strength glass for better sound control, thermal performance and greater security. AFG Clear coat Low E II Krypton Gas and Super Spacer are standard for superior thermal performance and reduced condensation. Specialty glazings such as tempered, tinted and decorative glass are also available.
• Double Weatherstripping - combines with a tight design for a .01 cfm/ft. air infiltration rating at 25 mph rated at DP 60.



Ultra-Fit Sash Pac Sash Replacement System



TrimLine Windows offers the Ultra-Fit Sash Pac sash replacement window system. Unlike typical wood sash replacement window systems, which merely provide a pair of loose compression style jambliners, the Ultra-Fit design unitizes its jambliner with a low profile head and sill plate, thereby ensuring a factory controlled sash opening.

The Ultra-Fit jambliner features a flexible blind stop flap to ensure a tight fitting weatherseal, while providing a seamless transition from the old window frame.

Custom made on every 1/8", the unit, which is field assembled, is installed in a similar manner as a conventional replacement window. Once the unit is secured in the opening the jambliner can be adjusted to remove any hour-glassing or bowing-out through the use of a specialized jamb adjusting screw.

The system employs the same E-Z Tilt sash, block and tackle balance system and hardware, as well as other available options on the Legend Series clad wood double hung replacement window. In addition, all wood and arched head sash with True Divided Lites are also available with this system.



Certified Rehabilitation approved by the National Park Service

TrimLine Windows provides quality custom windows for use in historically certified rehabilitation projects.

TrimLine offers a wide variety of products including double hung, casement, and bay windows as well as round top, elliptical and other architectural window products. Custom colors in either all wood or aluminum clad exteriors and interior hardwoods of oak, cherry, and mahogany as well as standard pine, are some of our company's offerings.

Additionally, custom panning systems, a variety of simulated divided light profiles, and replication of mullion details are some of the custom capabilities where maintenance of historical accuracy is essential.



Historic Windows features & benefits:

• Historically accurate custom panning systems
• Replication of mullion details
• Custom exterior colors
• National Park Service - Certified Rehabilitation
• Simulated divided lite systems
• Choice of hardwoods - Oak - Mahogany - Cherry
• Double Hung, Casements, Round Top, Elliptical Head, Radius casings
• Sash replacement systems
• High performance glass

Trimline Bow and Bay Windows

Add Beauty and Elegance through window design

Since 1964, Trimline Windows has produced quality custom aluminum clad wood windows for replacement, remodeling and new construction.

All TrimLine windows are custom made on the 1/8" in width and height. Standard and custom jamb depths combined with custom size make TrimLine windows suitable for replacement, remodeling and new construction.

The standard jamb depth is 4 9/16" and deeper jambs in one piece with extended sills and ears can be specified as needed to suit your building requirements.

Optional solid oak, mahogany or cherry interiors, brass hardware and decorative glass provide the exquisite look for that special room. A Cable Support System is standard and decorative knee braces are available.

All TrimLine bay and bow windows are fully assembled and ready to install in the opening



The underside of all Bay and Bow window seatboards include as standard a pre-finished ¾" fiberglass skinned EPS foam insulating panel.

The exteriors of all TrimLine windows use .055" thick extruded aluminum in a choice of white, bronze, earthtone or beige for extremely durable exteriors with the warmth and beauty of wood on the interiors.

Decorative leaded beveled glass options are offered in a variety of patterns and styles as are custom glass designs.

Grip-Tite™ - The Most Reliable and Trustworthy Cable Support System Designed for Bay/Bow Windows

The Grip-Tite™ cable support system provides a simple, very effective way to install projection windows. Through the use of its cleat design, not only are potential sagging problems eliminated, but the windows are easier to correctly install."


• Grip-Tite™ cleat provides no-slip feature that locks cable in place.
• Will not slip.
• Eliminates potential sagging problems.
• Greatly reduces need for field service calls.
• Simple and easy to install.
• Comes standard with all bay and bow windows.



Custom Architectural Window DesignsTo Fit Your Needs

Whether your tastes are traditional or contemporary, every TrimLine Decorative Window is made to compliment your imagination and design. And, regardless of the size, shape or style, every TrimLine window is individually handcrafted from the finest materials and with energy efficiency in mind.

• Circle units are manufactured with solid jambs to any wall thickness - no extension jambs required.
• Choice of all wood or maintenance free exteriors.
• Unit size and exterior casing is manufactured to line up for use over virtually any size or style double-hung or casement window or door unit.
• Choice of exterior casing and interior trim (style, width, thickness).
• Choice of glazing using insulating glass up to 1 ¼" thick. Low E, various tinted colors, and safetyglass also available.
• Choice of removable wood grilles in virtually any pattern or authentic muntin bars.



We Make Our Shapes To Fit Your Shapes

Whether your tastes are traditional or contemporary, every TrimLine Decorative Window is made to compliment your imagination and design. And, regardless of the size, shape or style, every TrimLine window is individually handcrafted from the finest materials and with energy efficiency in mind.



• Trapezoidal units are manufactured with jambs made to any wall thickness.
• Choice of all wood or maintenance free clad exteriors.
• Unit size and exterior casing is manufactured to line up for use over virtually any size or style double-hung or casement window or door unit.
• Choice of exterior casing and interior trim (style, width, thickness).
• Choice of glazing using insulating glass up to 1 ¼" thick. Low E, various tinted colors, and safetyglass also available.
• Choice of removable wood grilles in virtually any pattern or authentic muntin bars.

Construction

Solid-wood construction offers outstanding insulating qualities-in fact, wood provides 1,100 times the insulating value of aluminum.

Timline windows meet or exceed the Department of Energy's ENERGY STAR® standards. That energy-efficient performance can mean substantial savings on your heating and cooling bills.

ENERGY STAR®, windows are twice as efficient as the average windows manufactured just ten years ago. And money isn't all you're saving by purchasing products that use less energy - you're also helping to save the environment



Our windows…

 Reduce your heating and cooling costs
 Help the environment
 Make your home more comfortable
 Protect your home furnishings from ultraviolet rays
 Minimize health issues from mold and mildew

Energy efficiency



Low-E coating

Trimline windows are manufactured with ¾" double strength glass using AFG Industries Comfort Ti-R(™) Low-E glass coatings - Benefits:



• Year round energy savings - In the winter, Comfort Ti-R reflects heat back into the room, and solar energy easily enters through the glass, warming your home. In the summer, Comfort E2 stops as much as 65 percent of re-radiated solar heat from entering your home.
• Reduces heat transfer and UV rays that can fade carpets, walls and furniture.
• Reduces condensation by keeping glass warmer, which in turn, fights deterioration, mold, and stains on window casings.
• Provides unparalled color neutrality and high visible - light transmission - enabling you to see clearly, whether you are looking from the inside out or the outside in



Health Benefits

Super Spacer® technology dramatically reduces the amount of window condensation, which contributes to mold growth, whose occurrence is more and more being linked to child asthma, respiratory illness, allergies and outbreaks of fungal diseases.


Super Spacer® & Warm Edge Technology

Today more than ever, homeowners are replacing their old worn out windows with energy efficient replacement windows. Poorly insulated windows can attribute up to 25% of a building's heating and cooling loads.

In order to overcome the thermal inefficiency of conventional aluminum spacers, a new type of spacer product has evolved in the industry called 'warm-edge technology.' Warm-edge refers to the type of spacer material used to separate the panes of glass (or glazing) in an insulated window unit.

The world's warmest edge occurs with Super Spacer®, an insulating foam spacer whose use allows for comfortable humidity levels and the least likelihood of condensation, mold and other problems.
